Article Numbers (1h)
186804 (EMCc 60.006, 55V) / 186806 (EMCc 60.008, 105V) / 186808 (EMCc 60.010, 220V)
Article Numbers (3h)
186805 (EMCc 180.007, 55V) / 186807 (EMCc 180.009, 105V) / 186809 (EMCc 180.011, 220V)
Dimensions (LxWxH)
150 × 30.2 × 22.1 mm
Mains Voltage
220-240 V ±10%
Output Voltage
55 V / 105 V / 220 V (model dependent)
Output Power (Emergency)
2.5-3 W
Min Lumen (Emergency)
250 lm (at 100 lm/W per LED unit)
Operating Period
1 hr or 3 hrs nominal
Battery Material
Iron Phosphate (LiFePO4)
Battery Options
3.2V/3 Ah (1h types) / 3.2V/4.5 Ah (3h types) — Compact or Linear shape
Battery Ref Numbers
183202/183203 (3Ah C/L) / 183204/183205 (4.5Ah C/L)
Charging Time
Up to 24 hrs (depending on capacity)
Ambient Temperature
5 °C to 50 °C
SELV
186804, 186805, 186806, 186807
Surge Protection
3.75 kV (186804, 186805, 186806, 186807)
Compliance
VDE 0108 / EN 50172
Standards
EN 60598-2-22, EN 61347-2-7, EN 62384
Status LED
Green steady (charged) / Green blink (regenerating) / Off (fault)
Packaging Unit
50 pcs per box, 56 boxes per pallet
Manufacturer
Vossloh-Schwabe Deutschland GmbH
