Engineering Catalogue > Process Equipment > Date Coders > ANSER U2 Date Coder

ANSER U2 Date Coder

Print technology
Thermal Inkjet (TIJ)
Display
3.5" Color LCD with LED backlight
Input device
Pocket-sized IR remote keypad
Max print resolution
400 × 600 dpi (ProS / Smart / Diesel / MobileS); 400 × 300 dpi (SmartONE / MobileONE)
Max print speed
60.96 m/min @ 300 dpi
Max print height
12.7 mm (½") on most variants; up to 25.4 mm (1") on SmartONE & MobileONE
Recommended print distance
~6 mm from nozzle to surface
Print capabilities
Alphanumeric, logos, date/time, expiration, shift code, counter, lot box code, barcodes
Supported barcodes
Code-128, EAN-128, EAN-13/14/8, Code-39, ITF-14 (SCC-14), NVE (SSCC-18), PDF417, Data Matrix, GS1 (Datamatrix / DataBar / QR), QR Code, UPC-A/E, Codabar, Aztec, INTER25
Available languages
22+ incl. English, Serbian Latin, Serbian Cyrillic, German, Swedish, Russian, Chinese, Japanese, Korean, Spanish, French, Italian, Hungarian, Polish, etc.
Message storage
Up to 999 messages
Connectivity
RS-485, RS-232, USB, Wi-Fi; Ethernet on ProS
Power adapter
AC 100–240 V, 50/60 Hz
Operating temperature
5–40 °C (41–104 °F)
Dimensions
114 × 76 × 60 mm (stationary head)
Weight
0.49 kg stationary head (excl. cartridge); 1.13 kg mobile head
Mobile variants — battery
1840 mAh, 11.1 V; 4 h continuous print, 4.5–6 h standby
Standard accessories
Bracket set, power adapter, USB disk, IR remote control
Optional accessories
300 / 400 dpi encoder kit, photocell kit, Wi-Fi dongle, Ethernet dongle, U2 Bracket Plus, RS-485↔USB converter, Smart I/O kit, clock stabilizer
PC software
Message Pro II, Net Commander
Control protocol
ANSER U2 Net Protocol
Available variants
U2-ProS, U2-SmartONE, U2-Smart, U2-Diesel, U2-MobileS, U2-MobileONE
Key features
Zero-maintenance cartridge, anti-shock design, automatic ink identification, intelligent dashboard with real-time alerts
ANSER U2 Date Coder

ANSER U2 thermal inkjet printer family for product marking and traceability — date, expiration, lot code, barcodes (1D & 2D), logos. Up to 25.4 mm print height, 60.96 m/min @ 300 dpi. Six variants: ProS, SmartONE, Smart, Diesel, MobileS, MobileONE.

About ANSER U2 Date Coder

ANSER U2 Date Coder for thermal inkjet coding, variable data and barcode printing

Powered by Geoffy
What is this for?

Key features

  • Thermal Inkjet (TIJ) print technology
  • Prints dates, times and expiration information
  • Supports shift codes, counters and lot box codes
  • Prints alphanumeric characters, logos and barcodes
  • Up to 999 stored messages
  • 22+ available languages
  • RS-485, RS-232, USB and Wi-Fi connectivity
  • Ethernet connectivity on ProS

Common uses

  • Date and time coding
  • Expiration coding
  • Shift-code printing
  • Counter printing
  • Lot box code printing
  • Alphanumeric and logo printing
  • Barcode printing

The ANSER U2 Date Coder covers variable-data printing where dates, codes, text, logos or barcodes need to be produced. Its listed functions range from basic date and expiration marking to barcode and lot-box-code printing. The available connectivity options, message storage and language selection are also specified for the system.

Who is this for?

Production and process-equipment teams selecting a Thermal Inkjet date coder, Operators printing dates, expiration information, shift codes, counters or lot box codes, Teams requiring barcode, logo or alphanumeric printing, Sites comparing print height, resolution and speed across U2 variants, Multilingual operations using one of the listed interface languages, Installations requiring RS-485, RS-232, USB, Wi-Fi or, on ProS, Ethernet

The ANSER U2 Date Coder is for organisations and operators specifying a date coder by print content, output size, speed, connectivity and interface requirements. The relevant choice depends on the information to be printed, the required barcode format, the selected U2 variant and whether the installation needs Ethernet, Wi-Fi, serial or USB connectivity.

Common questions answered

What does the ANSER U2 Date Coder do for someone starting to specify a date coder?

The ANSER U2 Date Coder prints variable information using Thermal Inkjet technology, including dates, times, expiration information, shift codes, counters, lot box codes, alphanumeric content, logos and barcodes. It stores up to 999 messages and uses a 3.5-inch colour LCD with LED backlight. The system also supports 22 or more listed languages and can connect through RS-485, RS-232, USB or Wi-Fi, with Ethernet available on ProS.

Who should consider the ANSER U2 Date Coder for coding and identification work?

The ANSER U2 Date Coder is intended for teams that need to print dates, codes, text, logos or barcodes as part of process equipment. It is relevant when the specification includes Thermal Inkjet printing, stored messages, a selection of input languages or multiple connectivity interfaces. The supported content includes expiration information, shift codes, counters and lot box codes, rather than date printing alone.

Does the ANSER U2 Date Coder support different barcode requirements?

The ANSER U2 Date Coder supports a broad list of barcode formats, including Code-128, EAN-128, EAN-13/14/8, Code-39, ITF-14, NVE, PDF417, Data Matrix, GS1 formats, QR Code, UPC-A/E, Codabar, Aztec and INTER25. This makes the barcode requirement a direct selection check: the required symbology should be matched against this supported list before specification.

Which connectivity options and interface details are specified for the ANSER U2 Date Coder?

The ANSER U2 Date Coder specifies RS-485, RS-232, USB and Wi-Fi connectivity, with Ethernet listed on the ProS variant. It uses a pocket-sized IR remote keypad as its input device and a 3.5-inch colour LCD with LED backlight for display. The system can store up to 999 messages, while the available language list contains more than 22 options.

The ANSER U2 Date Coder is most relevant when the decision involves more than basic date printing. Buyers can compare variants by print height and resolution, check the barcode list against their required symbology, and confirm the available connectivity, language and message-storage specifications. The product data supports these technical checks without assigning a user skill level or production sector.

Specification
FieldValue
Print technologyThermal Inkjet (TIJ)
Display3.5" colour LCD with LED backlight
Input devicePocket-sized IR remote keypad
Max print resolution — ProS / Smart / Diesel / MobileS400 × 600 dpi
Max print resolution — SmartONE / MobileONE400 × 300 dpi
Message storageUp to 999 messages
Available languages22+ including English, Serbian Latin, Serbian Cyrillic, German, Swedish, Russian, Chinese, Japanese, Korean, Spanish, French, Italian, Hungarian and Polish
ConnectivityRS-485, RS-232, USB and Wi-Fi
Additional connectivity — ProSEthernet
Supported barcodesCode-128, EAN-128, EAN-13/14/8, Code-39, ITF-14 (SCC-14), NVE (SSCC-18), PDF417, Data Matrix, GS1 (Datamatrix / DataBar / QR), QR Code, UPC-A/E, Codabar, Aztec and INTER25
Why this product?

The ANSER U2 Date Coder brings date, variable-data and barcode printing into one specified Thermal Inkjet system. Its documented options include up to 999 stored messages, 22+ languages, multiple connection interfaces, variant-specific resolution and support for a wide range of barcode formats. These details help a buyer match the coder to required content and installation interfaces.

  • Prints dates, times, expiration information, shift codes, counters, lot box codes, alphanumeric content and logos
  • Supports the barcode formats listed in the product data, including Code-128, EAN, Data Matrix, QR Code and GS1 formats
  • Stores up to 999 messages
  • Provides a 3.5-inch colour LCD with LED backlight and a pocket-sized IR remote keypad
  • Offers RS-485, RS-232, USB and Wi-Fi connectivity
  • Adds Ethernet connectivity on the ProS variant
  • Lists 22+ available languages
  • Offers different maximum resolution and print-height specifications across the U2 variants
